Description
OREI UHD44-EXB400R-K: 4K HDBASET HDMI EXTENDER UPTO 400 FT
Key Features:
- HDMI 2.0b, HDCP 2.2, and HDCP 1 x compliant
- Video resolution up to 4K@60Hz and 2K@60Hz on all HDMI & HDBaseT ports
- 4 HDMI inputs, 4 HDMI & HDBaseT mirrored outputs
- HDMI ports transmit 18Gbps lossless uncompressed video bandwidth
- Supports 18Gbps lossless compressed HDBaseT signal transmission
- Supports 4K->1080P Down Scale function on each HDMI output port
- HDR, HDR 10, HDR 10+, Dolby Vision, and HLG are supported
- HDBaseT output can extend video transmission distance up to 492ft / 150m for 1080P or 394ft / 120m for 4K via a single Cat 5e/6/7 cable
- HDMI audio pass-through up to 7.1CH HD audio (LPCM, Dolby TrueHD, and DTS-HD Master Audio)
- Supports Bi-Directional IR control
- Audio de-embedded output is supported via analog and coax ports
- Advanced EDID management and CEC control are supported
- 24V POC on all HDBaseT ports
- 1U rack-mounted design with front panel OLED display
- Control via front panel buttons, IR remote, RS-232, LAN, and Web GUI
The UHD44-EXB400R-K can connect up to 4 HDMI sources and output to 8 displays. It features four HDMI outputs, and each HDMI output is mirrored to provide a CAT-Cable output that runs simultaneously.
It supports transmission of video with resolutions up to 4K@60Hz and 2K@60Hz. Audio de-embedded to analog and coaxial audio is supported. Each HDMI output supports a 4K to 1080P downscale function independently. HDBaseT output can extend video transmission distance up to 492ft/150m via a single Cat 5e/6/7 cable.
The product supports Bi-Directional IR control. The product provides an intuitive set of front panels with OLED screens and supports control via the front panel buttons, IR remote, RS-232, LAN, and Web GUI.
[shortdes]
- Video resolution up to 4K@60Hz and 2K@60Hz
- With bi-directional IR, RS-232, and CEC control
- HDR, HDR 10, HDR 10+, Dolby Vision, HLG
[/shortdes]
[tab]
CONNECTIVITY
| Transmitter: | INPUT: | 4 × HDMI INPUT [Type A, 19-pin female] |
| OUTPUT: | 4 × HDMI OUTPUT [Type A, 19-pin female] | |
| 4 × HDBaseT OUTPUT ports [RJ45] | ||
| 4 × Coaxial audio [3.5mm Stereo Mini-jack] | ||
| 4 × balanced analog audio [5-pin Phoenix connector] | ||
| Control: | 5 × IR IN [3.5mm Stereo Mini-jack] | |
| 5 × IR OUT [3.5mm Stereo Mini-jack] | ||
| 1 × TCP/IP [RJ45] | ||
| 1 × RS-232 [D-Sub 9] | ||
| Receiver: | INPUT: | 1 × HDBT IN [RJ45, 8-pin female] |
| OUTPUT: | 1 × HDMI Type A [19-pin female] | |
| 1 × AUDIO OUT [3.5mm Stereo Mini-jack] | ||
| Controls: | 1 × IR IN [3.5mm Stereo Mini-jack] | |
| 1 × IR OUT [3.5mm Stereo Mini-jack] | ||
| 1 × RS-232 [3-pin Phoenix connector] | ||
| 1 × SERVICE [Mini-USB, Update port] |
PACKAGE CONTENTS
| 1x UHD44-EXB400R-K |
| 1x IR Remote |
| 4x HDBaseT Receiver |
| 1x 100~240V AC 50/60Hz Power Cable |
| 1x RS-232 Serial Cable (1.5m, male to female head) |
| 4x 3-pin Phoenix Connector |
| 4x 5-pin Phoenix Connector |
| 5x IR Blaster Cable (1.5m) |
| 5x IR Receiver Cable (1.5m) |
| 10x Mounting Ear (Matrix and Receiver) |
| 1x User Manual |
SUPPORTED CAT CABLES
| CAT5e, CAT6, CAT7: | We recommend you use shielded CAT6 cables & High-Quality HDMI Cables for optimum performance |
EXTENDING DISTANCE
| 4K@60Hz: | 400 feet |
VIDEO OUTPUT
| Video Bandwidth: | 18Gbps |
| Video Resolutions: | Up to 4K@60Hz 4:4:4 |
AUDIO SUPPORT
| HDMI Audio: | LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD,Dolby Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X |
| Coax Audio Formats: | PCM 2.0, Dolby Digital / Plus, DTS 2.0/5.1 |
| HDR: | HDR 10, HDR 10+, Dolby Vision, HLG |
COMPLIANCES
| HDMI Compliance | HDMI 2.0b |
| HDCP Compliance | HDCP 2.2/1.x |
POWER
| Power Consumption: | 60W (Max) | |
| Power Supply: | AC 100 - 240V 50/60Hz |
DIMENSIONS & WEIGHT
| Transmitter: | Length: | 200mm |
| Width: | 440mm | |
| Height: | 44.5mm | |
| Weight: | 3.1kg | |
| Receiver: | Length: | 65mm |
| Width: | 140mm | |
| Height: | 18mm | |
| Weight: | 155g |
PROPERTIES
| Color: | Black |
| Housing: | Metal Enclosure |
| Operation Temperature: | 32-104°F / 0-40°C |
| Storage Temperature: | -4-140°F / -20-60°Ctd> |
| Relative Humidity: | 20~90% RH (Non-condensing) |
WARRANTY
| 1-Year Manufacturer's Warranty |
[/tab]
