Since 1998, Electrocompaniet has crafted one of the finest-sounding CD players on the market, the EMC 1 UP. The new EMC 1 MKV builds on this legacy, featuring a refined design with a new drive unit for enhanced performance. It also incorporates updated electronics, improved mechanics for a more rigid construction, and a redesigned chassis to align with the contemporary MKII editions of our other products.

Technology

This design prevents mechanical distortions from affecting the laser pickup, ensuring optimal playback quality.

Shielded Construction

The EMC 1 MKV features a no-compromise mechanical design with five distinct housings that shield analogue, digital, transport, transformer, and controller circuitry from interference.

Made in Norway

These all-in-one spike feet eliminate the common issue of surface damage caused by conventional spikes while effectively isolating the equipment from external vibrations.

Balanced Audio

The player is equipped with a fully balanced D/A converter and discrete analog audio circuitry, delivering exceptional sound quality.

Specs

• Output Level:
  • Unbalanced: 2.3 Vrms
  • Balanced: 4.6 Vrms
• Noise Floor: < -130 dB
• Frequency Deviation (20-20 kHz): 0.05 dB
• Channel Separation: > 110 dB
• THD+N: < 0.003%
• Dynamic Range: 120 dB
• Power Consumption: 25 W
• Digital/Analog Conversion: 24 bit/192 kHz
• Power Consumption (Standby): 0.5 W
• Compatible Formats: CD, CD-R, CD-RW
• Digital Outputs: SPDIF COAX, SPDIF TOSLINK
• Control Inputs: RS232, 12V Trigger
• Other:
  • True balanced system
  • Mechanical filter cancels acoustic/mechanical vibrations, preventing unwanted signals to the laser pick-up
  • Fully remote (no volume control)

Weight & Dimensions

• Weight: 18 Kg / 39.6 lbs
• Width: 470 mm / 18.5 inches
• Depth: 422 mm / 16.6 inches
• Height: 118 mm / 4.64 inches
