Description
OREI HD-202 : 2x2 HDMI Matrix Switch
- HDMI 2.0 & HDCP 2.2 compliant
- Video resolutions up to 4K@60Hz
- 18Gbps video bandwidth
- Audio extraction through Analog & Optical outputs
- EDID management through the switch on the front
- PCM 2.0 audio output through the analog output
- Optical audio support: LPCM 2.0/2.1CH, Dolby 5.1, Dolby True HD, Dolby DD+, DTS 5.1, DTS-ES 6/DTS-HDMA 5.1, DTS HD-HRA 5.1.
- HDR Support
- Compact design
- Plug & Play setup
The HD-202 Matrix Switch is a multiple input and multiple output switch which allows you to connect and switch between 2 inputs and 2 outputs. It supports video resolutions up to 4K@60Hz. You can also extract audio from the media stream that is going to OUT A through Optical and Analog 3.5mm ports. The device also features an EDID switch on the front along with the Switch buttons for the respective output ports. You can easily switch between sources using these buttons or the included remote.
[shortdes]
- 2 Inputs - 2 outputs HDMI Matrix switch
- Video resolution up to 4K2K@50/60Hz YCbCr 4:4:4 - EDID Control
- Supports Dolby Vision, HDR 10+
- Compliance: HDCP 2.2, 1.x
[/shortdes] [tab]
AUDIO AND VIDEO
| Inputs: | 2×HDMI Type A [19-pin female] |
| Output Ports: | 2×HDMI Type A [19-pin female] |
| 1×L/R [3.5mm Stereo Mini-jack] | |
| 1×OPTICAL OUT [Optical jack] | |
| Video Bandwidth: | 594MHz / 18Gbps |
| Video Resolution: | Up to 4K2K@50/60Hz YCbCr 4:4:4 |
| Color Space: | RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 |
| HDMI Audio Formats: | PCM2.0/5.1/7.1CH, Dolby 5.1, DTS5.1, Dolby-TrueHD, DTS-HD |
| L/R Audio Formats | Analog stereo PCM 2.0 |
| Optical Audio Formats | LPCM[2.0/2.1]CH, Dolby 5.1, Dolby True HD, Dolby DD+, DTS 5.1, DTS-ES 6, DTS-HDMA 5.1, DTS HD-HRA 5.1 |
COMMUNICATION AND CONTROL
| HDMI Compliance | HDMI 2.0 |
| HDCP Compliance | HDCP 2.2 |
| DVI Compliance | DVI 1.0 |
POWER
| Power Supply: | Input: AC100~240V 50/60Hz Output: DC5V/1A (US/EU standard, CE/FCC/UL certified) |
| Power Consumption | 2.7W |
CONTROL
| CEC | Pass through |
ENVIRONMENTAL
| Operating Temperature: | 0°C ~ 40°C / 32°F ~ 104°F |
| Storage Temperature: | -20°C ~ 60°C / -4°F ~ 140°F |
| Relative Humidity | 20~90% RH (non-condensing) |
DIMENSIONS & WEIGHT
| Height | 18mm |
| Width | 59.5mm |
| Depth | 144mm |
| Weight | 208g |
REGULATORY
| Safety and Emission: | CE | FCC | RoHS |
PACKAGE CONTENTS
| 1 × HD-202 Matrix |
| 1 × Power Adapter |
| 1 × Matrix IR Remote |
| 1 × User Manual |
Warranty
| 1 - Year Manufacturer's Warranty |
[/tab]
[tab1]
FAQs
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
No, our switchers aren't compatible with capture cards
Yes, the included power adapter does support 220V
Please email us on [email protected]
