Description
OREI UHD-402D: 4x2 HDMI Matrix UltraHD with ARC Audio Extraction
- HDMI 2.0, HDCP 2.2 compliant
- 18Gbps video bandwidth
- Input and output video resolutions support up to 4K@60Hz 4:4:4
- Optical audio support for audio formats up to LPCM, Dolby & DTS up to 5.1CH
- L/R audio support for audio formats up to LPCM 2.0CH
- Switch between the 4 inputs on a single display or 2 displays or split any of the 4 inputs into 2 displays
- ARC Audio extraction support, to extract audio from the HDMI sources or from an ARC TV. Audio output via S/PDIF (Optical) and analog outputs
- Advanced EDID management
- Robust build with a plug and play installation
- Perfect for personal and commercial uses
The UHD-402D is a versatile HDMI Matrix designed to enhance your audio and video experience. It supports HDMI 2.0 and HDCP 2.2 compliance, with video resolutions up to 4K@60Hz YUV 4:4:4 and HDR support. This device features separate audio outputs for both HDMI outputs A & B, with ARC support for output A. It boasts a high bandwidth of 600MHz/6Gbps per channel (18Gbps all channels). In addition, it includes a 4K to 1080p Downscale feature when in Splitter mode. With support for uncompressed LPCM audio and various compressed audio formats such as DTS and Dolby Digital. Whether for home entertainment systems or professional setups, the UHD-402D offers reliable performance and advanced features to enhance your viewing and listening pleasure.
[shortdes]
- 4 in 2 out HDMI Matrix Switch with HDR & downscaling
- Resolutions up to 4K@60Hz 4:4:4
- ARC Audio extraction with output via Optical and L/R ports
[/shortdes]
[tab]
CONNECTIVITY
| INPUT: | 4 × HDMI [Type A, 19-pin female] | |
| OUTPUT: | 2 × HDMI [Type A, 19-pin female] | |
| 2x S/PDIF (Optical) | ||
| 2 × L/R Audio [5 pin Phoenix connector] |
PACKAGE CONTENTS
| 1x UHD-402D HDMI Matrix Switch with Audio Extraction |
| 1x IR Remote Control |
| 1x Power Adapter |
| 1x USB-A to USB-C Power Cable |
| User Manual |
SUPPORTED HDMI CABLES
| HDMI 2.0 / 2.1 | We recommend using high-quality HDMI 2.0 / 2.1 cables under 30 feet for optimum performance |
EXTENDING DISTANCE
| 4K@60Hz: | 30 Feet |
VIDEO OUTPUT
| Video Bandwidth: | 18 Gbps |
| Video Resolutions: | Up to 4K@60Hz 4:4:4 |
ADDITIONAL FEATURES
| CEC: | No |
| ARC: | Yes |
| USB KVM: | No |
| PoC/PoE: | No |
| IR Control: | Yes |
| Downmix: | No |
| Downscale: | Yes |
| Over IP: | No |
| HDBaseT: | No |
| RS-232: | No |
AUDIO SUPPORT
| HDMI Audio Formats: | Compressed audio such as DTS, Dolby Digital (including DTSHD Master Audio™ and Dolby TrueHD) |
| Coaxial Audio Formats: | LPCM 2.0CH/Dolby/DTS 5.1CH |
| L/R Audio Formats: | LPCM 2CH |
COMPLIANCES
| HDMI Compliance | HDMI 2.0 |
| HDCP Compliance | HDCP 2.2 |
POWER
| Power Consumption: | 5W (Max) | |
| Power Supply: | Input: 100 - 240V 50/60Hz | |
| Output: DC 5V/2A |
DIMENSIONS & WEIGHT
| Length: | 171mm / 6.73in | |
| Width: | 61mm / 2.4in | |
| Height: | 20mm / 0.78in | |
| Weight: | 245g / 8.61oz |
PROPERTIES
| Color: | Black |
| Housing: | Metal Enclosure |
WARRANTY
| 1-Year Manufacturer's Warranty |
[/tab]
