Description
BK-401: 8K 4 Input 1 Output HDMI Switch
Key Features:
- HDMI 2.1 and HDCP 2.3 compliant
- 48Gbps video bandwidth
- Video resolutions up to 8K@60Hz, 4K@120Hz
- HDR/10+, Dolby Vision, HLG pass through
- VRR (Variable Refresh Rate), FVA(Fast VActive), ALLM (Auto Low Latency Mode) support
- Audio support: LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
- Supports automatic switching
- Compact design
The BK-401 8K HDMI Switch is an impressive solution for connecting multiple media sources to a single display and switch between them as needed. This device accepts media signals from 4 sources and outputs it on a single display. It supports resolutions up to 8K@60Hz and 4K@120Hz with a video bandwidth of 48Gbps. It supports HDR10+ and Dolby Vision along with Variable Refresh Rate, Fast VActive and Auto Low Latency Mode. The device also features automatic switching which automatically switches to the next active input.
[shortdes]
- 4 In 1 8K Switcher
- Video Resolutions up to 8K@60Hz
- Automatic switching
[/shortdes]
[tab]
CONNECTIVITY
| INPUT: | 4 × HDMI [Type A, 19-pin female] | |
| OUTPUT: | 1 × HDMI [Type A, 19-pin female] |
PACKAGE CONTENTS
| 1x BK-401 |
| 1x Remote Control |
| 1x Power Adapter |
| User Manual |
SUPPORTED HDMI CABLES
| HDMI 2.1 | We recommend using high-quality HDMI 2.1 cables under 30 feet for optimum performance |
EXTENDING DISTANCE
| 8K@60Hz: | 6 Feet |
| 4K@120Hz: | 6 Feet |
| 1080p@240Hz: | 16 Feet |
VIDEO OUTPUT
| Video Bandwidth: | 48 Gbps |
| Video Resolutions: | Up to 8K@60Hz, 4K@60Hz, 2K@120Hz, 2K@60Hz |
ADDITIONAL FEATURES
| CEC: | No |
| ARC: | No |
| USB KVM: | No |
| PoC/PoE: | No |
| IR Control: | Yes |
| Downmix: | No |
| Downscale: | No |
| Over IP: | No |
| HDBaseT: | No |
| RS-232: | No |
AUDIO SUPPORT
| HDMI Audio Formats: | LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD |
COMPLIANCES
| HDMI Compliance | HDMI 2.1 |
| HDCP Compliance | HDCP 2.3 |
POWER
| Power Consumption: | 3.4W (Max) | |
| Power Supply: | Input: AC 100-240V 50/60Hz | |
| Output: DC 5V/1A |
DIMENSIONS & WEIGHT
| Length: | 122mm / 4.8in | |
| Width: | 65mm / 2.56in | |
| Height: | 19mm / 0.75in | |
| Weight: | 88g / 3.10oz |
PROPERTIES
| Color: | Black |
| Housing: | Plastic Enclosure |
WARRANTY
| 1-Year Manufacturer's Warranty |
[/tab]
